Oralite 5710 Engineer Grade Premium

A glass-bead reflective film for permanent traffic signs, Oralite 5710 Engineer Grade Premium is certified to EN 12899-1 at Class RA1. This lightly speckled reflective has a smooth surface perfect for printing.

5710 Spec Sheet

Colours

Roll Widths 760mm 920mm 1235mm 1520mm

Class RA1 – UKCA/CE EN12899-1

Oralite 5710 Engineer Grade Premium is designed for small scale traffic signs that are generally viewed by pedestrians instead of drivers. Such as local parking and loading restrictions, which require moderate levels of visibility. This speckled, glass-bead film is certified to EN 12899-1 and CE/UKCA accredited at RA1. And features a smooth surface that is both screen and digitally printable. Or you can combine it with 5071 lettering film for cut graphics applications.

Oralite 5710 has a 7 year durability and 7 colours that come in 760mm, 920mm, 1235mm and 1520 widths. In addition, a selection of compatible overlay help this reflective to maintain its durability & visibility. The ORAFOL webpage for Oralite 5710 Engineer Grade Premium has more details, data sheets, certificates & application instructions.

Oralite 5710 Quick-Specs

Film: Oralite 5710 Engineer Grade Premium
Tech: RA1 Glass Bead Film
Roll Widths: 760 / 920 / 1235 / 1520mm
Roll Length: 50 metre rolls
ST Colours: 0.130mm thick
Variant: V5717 Digital Print

Material Details

Reflective Class: RA1 – UKCA/CE Certified
Standard: EN 12899-1 / NHSS
Alkyd Film with Silicone Paper Liner
Technology: Glass Bead
Durability: 7 year life
Colours: 7 Standard
Pressure Sensitive Adhesive for Metallic Surfaces

Compatible Products

Digital Ink: 5019i (uv) / 5017 (eco)
Transparent Film Overlay: 5051
Anti-Graffiti Overlay: 5095
Anti-Dew Overlay: 5090
Lettering Film: 5071

Colours & Pattern

Colours & patterns shown below are for illustration purposes and may not match actual films. Click for slightly larger swatches.

Standard Colours

5710-010-White

010 White

5710-020-Yellow

020 Yellow

5710-030-Red

030 Red

5710-035-Orange

035 Orange

5710-050-Blue

050 Blue

5710-060-Green

060 Green

5710-080-Brown

080 Brown

Oralite 5710 Downloads

The Orafol website has a selection of certificates, instructions & data sheets for Oralite 5710. Below you will find a set of external links going to some of those downloads. Please note, film brochures, a declaration of performance and links to compatible materials are also available.
